The SENSAR™ IOL offers high-quality lens design, materials and optics that can be expected from Johnson & Johnson intraocular lenses.
| DESCRIPTION | AR40M | AR40E | AR40e |
|---|---|---|---|
OPTIC CHARACTERISTICS | |||
Power: | -10.0 D to +1.5 D in 0.5 diopter increments | +2.0 D to +5.5 D in 0.5 diopter increments | +6.0 D to +30.0 D in 0.5 diopter increments |
Diameter: | 6.0 mm | 6.0 mm | 6.0 mm |
Shape: | Biconvex Meniscus | Biconvex Meniscus | Biconvex |
Material: | UV-blocking hydrophobic acrylic | UV-blocking hydrophobic acrylic | UV-blocking hydrophobic acrylic |
Edge Design: | OptiEdge™ with 360° square edge, and round anterior edge | OptiEdge™ with 360° square edge, and round anterior edge | OptiEdge™ with 360° square edge, and round anterior edge |
OPTICAL BIOMETRY | |||
A-Constant (SRK/T): | 118.7 | 118.7 | 118.7 |
AC Depth (HofferQ): | 5.41 mm | 5.41 mm | 5.39 mm |
Surgeon Factor (Holl.1): | 1.63 mm | 1.63 mm | 1.62 mm |
APPLANATION ULTRASOUND BIOMETRY | |||
A-Constant:† | 118.4 | 118.4 | 118.4 |
Theoretical AC Depth: | 5.2 mm | 5.2 mm | 5.2 mm |
Surgeon Factor: | 1.45 mm | 1.45 mm | 1.45 mm |
HAPTIC CHARACTERISTICS | |||
Overall Length: | 13.5 mm | 13.5 mm | 13.0 mm |
Style: | Modified C | Modified C | Modified C |
Material: | 60% Blue Core Polymethylmethacrylate (PMMA) Monofilament | 60% Blue Core Polymethylmethacrylate (PMMA) Monofilament | 60% Blue Core Polymethylmethacrylate (PMMA) Monofilament |
Angle: | 5° | 5° | 5° |
RECOMMENDED INSERTION INSTRUMENTS | MODEL | MODEL | MODEL |
The UNFOLDER™ Emerald XL Series Handpiece | EMERALDT | EMERALDT | EMERALDT |
The UNFOLDER™ Emerald XL Series Cartridge | EMERALDC30 | EMERALDC30 | EMERALDC30 |
Recommended insertion instruments:
The UNFOLDER™ EMERALD Series Implantation System: Intuitive push-and-twist, screw-style insertion designed to simplify lens implantation.
1. SENSAR™ 3-p AR40e -10.0 D – +30.0 D – DFU OUS – Z311736P, current revision.
2. SENSAR™ 3-p AR40E-AR40M -10.0 D – +5.5. D – DFU OUS – Z311585P, current revision.
3. 150 – Data On File – SENSAR™ not associated with glistening – Literature analysis. May 2013. REF2014OTH0002.
4. Zhao H, Mainster MA. The effect of chromatic dispersion on pseudophakic optical performance. Br J Ophthalmol. 2007;91(9):1225-1229. REF20140029.
5. Mainster MA. Violet and blue-light blocking intraocular lenses: Photoprotection versus photoreception. Br J Ophthalmol. 2006;90:784-792. REF2014MLT0013.
6. SENSAR 3-Piece Spec Sheet (AR40M, AR40E, AR40e) ANZ. 2025PP15911.
